5.9 Change language selection
select
Language options: NL, EN, DE, FR, IT, PL, RO, LT.

5.10 Calibration

If the assembly site is not suitable for the external sensor, a defect may occur in the temperature
actually measured by the PinTherm Infra II. This temperature difference can be compensated by
setting a correction value with this calibration function.
Example: The temperature measured amounts to 18°C, the screen on the PinTherm Infra II
indicates 20°C. The difference in this example therefore amounts to 2°C too high
the correction value must therefore be set to -2°C.
select
5.11 Changing high/low setting
select
High/low setting can be adjusted to
- High/low manual
- High/low automatic 1K
- High/low automatic 2K
- High/low automatic 3K
In the automatic position, the Infra will automatically go 1.2 or 3K under the required
temperature to operating position low.
12
CHANGE LANGUAGE
CALIB. TEMP.
SETTING
HIGH/LOW
SELECT LANGUAGE
ENGLISH
OK
select the desired
language
CALIB. TEMP.
+ 0.0°C
OK
changes the
flashing digit
to go one digit up
Correctionvalue is adjustable
from -3,5°C to +3,5°C
HIGH/LOW
MANUAL
OK
change setting
OK
back to the
menu
OK
back to the
menu
OK
back to the
menu
