DMX controlled operation

Setting the number of DMX channels and the DMX starting address
For operation with a controller with DMX512 protocol, the device is equipped with 8 control channels.
However, it can also be switched to a mode with 3, 4-1, 4, or 6 channels if different functions are required.
To be able to operate the device with a DMX controller, the DMX starting address must be set. The starting
address depends upon which DMX controller is being used. Please refer to the controller's documentation.
1 Press the MENU button so many times until Addr is indicated in the display. Confirm with the ENTER
button.
2 The display indicates 3 CH (3 DMX channels), 4-1 CH (4-1 DMX channels), 4 CH (4 DMX channels), 6
CH (6 DMX channels) or 8 CH (8 DMX channels). Use the buttons UP and DOWN to select the desired
DMX channels mode. Confirm with the ENTER button.
3 Now the display indicates the menu item for the DMX start address. Use the buttons UP and DOWN to
set the address. Confirm with the ENTER button.
4 When receiving DMX control signals, the display doesn´t flash. If no DMX control signals are available,
the display will flash.
Note: Please make sure that you do not have any overlapping channels in order to control each device
correctly and independently from any other fixture on the DMX chain. If several devices are addressed
similarly, they will work synchronically.
Functions in DMX mode
3-channel mode
Channel
CH1
CH2
CH3
4-1-channel mode
Channel
CH1
CH2
CH3
CH4
Value Function
000 – 255 Red 0-100%
000 – 255 Green 0-100%
000 – 255 Blue 0-100%
Value Function
000 – 255 Red 0-100%
000 – 255 Green 0-100%
000 – 255
Blue 0-100%
000 – 255 White 0-100%
