Cleaning And Maintenance - eder Titan 80 Pro Bedienungsanleitung

309001_00 | 03.2023
Damage to the felling wedge
The Titan 80 radio felling wedge is protected according to
IPX4. Do not submerge it and do not expose it to water jets.

Cleaning and maintenance

Clean the felling wedge with a dry cloth.
>
Do not use any grease-dissolving, caustic or aggressive
>
cleaning agents.
Clean the device from wood residues, chips and other dirt.
>
Sufficient lubrication of all rotating and sliding parts is
>
important for a long service life.
Grease is pressed through the three lateral grease nipples into
>
the device and onto the sliding surfaces between the wedge
and the spring steel plates with the help of a grease gun when
the wedge is retracted.
Regrease the wedge of the felling wedge after each felling
>
operation.
Regrease the bearing (grease nipple in the aluminium housing)
>
once a year.
Store the felling wedge in a dry place and protect it from dirt,
>
dust and moisture.
Risk of damage to the felling wedge due to moisture!
If the felling wedge has been exposed to moisture, relubrication is
required immediately.
ATTENTION
ATTENTION
Titan 80 Pro, Funk Titan 80, Titan 50 52
