41 Titan 80 Pro, Funk Titan 80, Titan 50
Notching
When the direction of fall of the tree to be felled has been determined,
you must cut the notch. The notch is made toward the direction of fall.
To cut the notch, proceed as follows:
Make the horizontal cut and the wedge cut.
>
Felling direction
Notched roof
Drop notch roof
Risk of injury due to tree breaking off prematurely!
Make sure that the top and bottom cuts of the notch meet exactly.
They must also not be too deep, as the tree will then break off
prematurely, which can lead to serious injuries.
Make the top and bottom cuts of the notch meet exactly.
>
The depth of the notch should be 1/5-1/3 of the trunk diameter and the
notch angle 45°-60°.
CAUTION
EN
~45°-60°
