45 Titan 80 Pro, Funk Titan 80, Titan 50
Risk of damage to the felling wedge due to incorrect operation!
If you do not insert the felling wedge horizontally and
approximately at a 90° angle to the breaking bar, the unit may be
damaged.
Check that the felling wedge is aligned with the felling
>
cut and that the lifting wedge can spread the felling cut
without obstruction.
Check that the felling wedge cannot hit the breaking
>
strip.
Do not hit the felling wedge with a hammer.
>
Lubrication and cleaning of the felling wedge
The maximum lifting power and service life can only be achieved
with sufficient lubrication and clean running. Dry running under
load can lead to damage.
Lubricate and clean the felling wedge before each felling
>
operation.
ATTENTION
EN
309001_00 | 03.2023
