309001_00 | 03.2023
Device pairing
If the remote control needs to be relearned or replaced, it can be re-
paired with the radio falling wedge. With the remote control switched
on, briefly press the "Forward" and "Reset" buttons simultaneously; the
status LED then flashes red. Now press and hold the "Forward" and
"Reset" buttons simultaneously until the status LED goes out and the
signal LEDs start to light up one after the other. Shortly afterwards, the
serial number of the felling wedge is saved and the remote control
automatically returns to normal operation.
If the remote control cannot pair with the felling wedge, check that the
felling wedge battery is charged and inserted and that the distance
between the units is not too great.
Caution: The function remains active for 1 minute, then the remote
control switches off.

Functions of the LED displays for Funk Titan 80

LED Function
State (no.8) Fast³ green/orange
flashing
Fast³
flashing
Red on
Red flashing 5-times
slowly red² flashing
Signal (no.4) All flashing
Middle on
Lighting up from left
to right
Reset (no.2) on
fast³ flashing
1. The remote control is protected against reverse polarity. However, the
remote control will not work if the batteries are inserted incorrectly.
2. Slowly flashing =0,5s intervall
3. Fast flashing = 0,1s intervall
Meaning
Felling
empty
orange Remote control batteries
almost empty and felling
wedge battery empty
Remote control batteries
almost empty
Remote control batteries
empty
Emergency stop active
no signal from felling
wedge
Signal from felling wedge
Ok
Pairing of remote control
and felling wedge
Reset function active
Travel of the wedge is not
saved
Titan 80 Pro, Funk Titan 80, Titan 50
wedge battery
