Felling the tree

Make sure that there are no other people or objects in the felling
>
area.
Give warning signs such as "Attention! Tree falling!"
>
Operate the ratchet or impact wrench clockwise so that the lifting
>
wedge made of special plastic pushes forward and gradually
causes the tree to fall.
Keep pushing the safety wedge until the tree falls.
>
Move out of the danger zone quickly.
>
Keep an eye on the crown and nearby trees.
>
Stay in a safe area until the tree is on the ground and there are no
>
more dangers.
If the full extension length has been reached but the tree has not
>
yet fallen, you must reposition the Titan 80 Pro. To do this, follow
the steps below:
The tree must be secured by sufficiently high safety wedges.
>
Operate the ratchet or impact wrench anti-clockwise to retract the
>
lifting wedge.
Reposition the felling wedge and repeat the lifting process by
>
turning the ratchet or impact wrench clockwise.
Risk of damage to the felling wedge
The shaft drive is mechanically limited. When the full extension
length of the lifting wedge is reached, do not turn the ratchet or
impact wrench any further clockwise.
Never turn the ratchet with force and never extend it.
>
Do not use an impact wrench with more than 1360 Nm
>
on the Titan 80 Pro.
Do not use an impact wrench with more than 750 Nm on
>
the Titan 50.
