OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. You can move through the main menu by turning the encoder. Press the encoder to select the desired
menu item. You can change the selection by turning the encoder. Confirm each change by pressing the
encoder. The respective mode can be exited via the "Quit" menu item. The respective functions are
described below. All settings remain stored even if the device is disconnected from the mains. The device
can be operated either in standalone mode via the encoder or in DMX-controlled mode via a commercially
available DMX controller.
Encoder:
Selects the operating mode
Activates a value to be modified or saves a value when modifying

Menu structure

Default setting shaded:
Disply
DMX Address
CCT
HSI
RGB
Curve
Mode
PWM rate
Correcting
A001 Setting the DMX-Starting address A001 – A512
ColorTemp Setting the color temperature 1800K – 10000K
Intensity Setting the total brightness 000 – 255
Strobe Setting the strobe speed 000 – 012 (increasing)
Hue Setting the hue 000 – 255
Saturation Setting the saturation 000 – 255
Intensity Setting the brightness 000 – 255
Strobe Setting the strobe speed 000 – 012 (increasing)
Setting the dimmer intensity of the LED colors – color
mixing, 000 – 255 (increasing)
Red Dimmer intensity of the red LED colors 000 – 255
Green Dimmer intensity of green LED colors 000 – 255
Blue Dimmer intensity of blue LED colors 000 – 255
White Dimmer intensity of white LED colors 000 – 255
Intensity Setting the total brightness 000 – 255
Strobe Setting the strobe speed 000 – 012 (increasing)
Setting the dimmer curves
Dimmer curve: Linear;
Curve Dimmer curve: Exponential;
Dimmer curve: Logarythmic;
Dimmer curve: S-type
5CH Setting the 5-channel mode
6CH Setting the 6-channel mode
9CH Setting the 9-channel mode
Pulse-width modulation
With this function the PWM frequency of the LEDs can
PWMrate
be set: 800Hz, 1200Hz, 2000Hz, 3600Hz, 12000Hz,
15000Hz, 25000Hz
ON Color correction on
OFF Color correction off
Function
