Installation
1.
Depending on the wall condition, fasten the bracket (A) either directly to the wall with wood
screws (B), see Fig. 1.1. or by inserting the threaded bushes (D) into the wall with the metric
screws (C), see Fig. 1.2. For this purpose pre-drill two Ø 6.5 mm holes in the wall.
A
B
Connection with wood screws
2.
Push countersunk screw (E) through the bracket from below.
3.
Screw it to bolt (F).
4.
Place holder (G) on bolt (F).
5.
Push on cover (H).
6.
Insert glass bowl (I).
1.1
C
A
D
Connection with threaded bushes
I
6.
1.2
Core hole Ø 6.5 mm
H
5.
G
4.
F
3.
E
2.
13
