7.13 Select the backlit RGB color of the 8 pads

Press the MENU button repeatedly until the display reads "Pad color R/G/B" to start the function of selecting
the backlit color of 8 the pads. When this function is valid, the display reads the "Pad color R/G/B" and the
current RGB color number. R is for red, G is for green and B is for blue. It can be adjusted via the value dial
and confirmed by the Enter button. The initial value is 127, adjusting scale is 0～255.
For example, you may want to set Pad 1 with RED color for the backlight. This is done by setting the Pad
color R to 127, Pad color G to 0 and Pad color B to 0 to the Pad 1. The operation steps are shown as below
and the display reads the following:
(1) Trigger Pad 1.
(2) Press the MENU button repeatedly until the display reads "Pad color R".
(3) Rotate the value dial until the display reads 127.
(4) Press the "Enter" button to confirm and the display shows "Done".
(5) Press the MENU button repeatedly until the display reads "Pad color G".
(6) Rotate the value dial until the display reads 0.
(7) Press the "Enter" button to confirm and the display shows "Done".
(8) Press the MENU button repeatedly until the display reads "Pad color B".
(9) Rotate the value dial until the display reads 0.
(10) Press the "Enter" button to confirm and the display shows "Done". Hold the "Enter" button for 2 seconds
to exit the edit mode and return to parameter display mode. Then if you rotate the knobs, move the
sliders or trigger the pads the display will show the current parameters of these controllers.
Reference RGB numbers for some colors:
Color
White
Black
Red
Green
Blue
Cyan
Magenta
Yellow
Orange
R G
127 127
0 0
127 0
0 127
0 0
0 127
127 0
127 127
127 82
B
127
0
0
0
127
127
127
0
0
