OPERATING INSTRUCTION
Table 3: Alarm/Health Operation
ZSE18 / ZEO18
-xx_xxx = Q2 output
Health/Alarm is always the Q2 output
Health, PNP (≤ 100 mA)
en
Alarm, PNP (≤ 100 mA)
Health, NPN (≤ 100 mA)
Alarm, NPN (≤ 100 mA)
28 O P E R A T I N G I N S T R U C T I O N | ZSE18
-xxRxxx
-xxTxxx
-xxQxxx
-xxSxxx
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
+ (L+)
Q
‒ (M)
