C
• To install virtual boundaries in an area with an U-
shaped object higher than 1 m / 3.3 ft, make sure
that the distance (E) is minimum 6 m / 20 ft. If the
object is higher than 3 m / 10 ft., make sure that
the distance (E) is twice the height of the highest
object. Install the virtual boundary at a minimum
distance (D) of 1.5 m / 5 ft. from the object.
D
D
E
• For areas between objects higher than 1 m / 3.3 ft.
the distance (F) must be minimum 4 m / 13 ft.
110 - Installation
C
D
D
F
Note:
For areas with a width less than 4 m / 13
ft. a transport path can be made for the robotic
lawn mower to go through without cutting.
39.9.1 Passages
A passage is a section that has virtual boundary on each
side and that connects 2 parts of the work area. The
passage must be a minimum of 2 m / 6.5 ft. wide to get
a good cutting result.

39.9.2 To install the map objects in a slope

The product can operate in 50% slopes. Do not include
too steep slopes in the work area. Too steep slopes
can be isolated as stay-out zones. The slope (%) is
calculated as height for each m. Example: 10 cm / 100
cm = 10%.
10%
10 cm/4"
• For slopes more than 50% in the work area, isolate
the slope with a stay-out zone.
• For slopes that are more than 25% along the outer
edge of the lawn. For installation of the virtual
boundary, operate the product with the rear wheel
5 cm / 2 in. (A) from the edge.
100 cm/40"
