38.1.5 System overview

1
2
8
12
1. Satellites
2. Satellite signals
3. Reference station
4. Correction data
30
5. Charging station
6. Virtual boundary
7. Stay-out zone
8. Work area
31
9. Mobile device
10. Docking point
11. Transport path
12. Robotic lawn mower with EPOS

38.1.6 Symbols on the product

These symbols can be found on the product. Make sure
that you understand them.
30
Not included.
31
Not included.
32
Robotic lawn mower not included.
1944 - 001 - 13.01.2023
2
4
11
10
7
™ 32
Plug-in Kit
3
5
6
8
9
This product complies with the applicable
EU Directives.
This product complies with the applicable
UK Directives.
It is not permitted to dispose the product
as usual domestic waste. Obey national
regulations and use the local recycling
system.
