4
Operation
The step switch allows you to switch from a low belt speed to a higher belt speed.
If the drive is overloaded, the motor-protective circuit-breaker may trip. To reset the motor pro-
tection switch, press the button on the rear of the unit.
4.1
Adjusting the belt run correctly
ATTENTION!
Pull out the mains plug and first move the sanding belt by hand in order to estimate the
correct running of the sanding belt and to roughly adjust it. Only then switch on the belt
grinder and then readjust the run of the sanding belt with the knurled screw (1).
The belt run is adjusted by adjusting the knurled screw (1) at the front of the belt. By screwing in
the knurled screw, the tape reel moves in direction A. By unscrewing the knurled screw, the reel
moves in direction B. The sanding belt changes direction in opposite directions.
1
4.2
Surface grinding
Open the lid at the top and fold it back. Place the workpiece on top of the sanding belt, place it
against the counter stop and press it down.
Operation
Version 1.0.2 - 2021-9-30
AB
Translation of original instruction
GB100S
EN
31
