• Check the certainty of embedding the dust container on the dust
outlet stub by lightly pulling the dust container
Operation and maintenance of the grinder
ON/OFF
The mains voltage must correspond to the voltage stated on the
nameplate of the grinder.
On - switch the switch button (1) in item I (Fig. E).
Shutdown - switch the switch button (1) in the O position.
OSCILLATING GRINDER WORK
• During operation, the entire grinding surface of the working foot
must rest on the workpiece surface.
• Apply moderate pressure to the grinder, move it over the
material being processed with rotational movements, in a
transverse or longitudinal direction.
• For rough work use sandpaper with coarser grain, and for
finishing work with fine grain. The type of sandpaper is best
selected by trial.
• When finishing polishing, reduce the pressure on the grinder and
lift it above the workpiece and only then turn it off.
OPERATION AND MAINTENANCE
Before proceeding with any installation, adjustment, repair or
maintenance activities, remove the plug of the power cord from
the mains outlet.
MAINTENANCE AND STORAGE
It is recommended to clean the device immediately after each use.
Do not use water or other liquids for cleaning.
• The device should be cleaned with a brush or blown with low-
pressure compressed air. Do not use any cleaning agents or
solvents, as they may damage plastic parts.
• Regularly clean the ventilation gaps in the engine housing to
prevent overheating of the device.
• In the event of excessive sparking on the commutator, have the
condition of the carbon brushes of the engine checked by a
qualified person.
• Always keep the device in a dry place, out of reach of children.
REPLACEMENT OF CARBON BRUSHES
Worn (shorter than 5 mm), burnt or cracked carbon brushes of
the motor should be replaced immediately. Both brushes are
always replaced at the same time.
The operation of replacing carbon brushes should be entrusted
only to a qualified person using original parts.
All kinds of defects should be removed by the manufacturer's
authorized service
RATINGS
Oscillating grinder 59G329
Parameter
Supply voltage
Power frequency
Power
Power cord length
No-load speed range
Grinding foot dimension
Protection class
IP rating
Mass
Year of manufacture
59G329 means both the type and the designation of the
NOISE AND VIBRATION DATA
Acoustic pressure level
Sound power level
Vibration acceleration value
Information on noise and vibration
Value
230 VAC
50 Hz
380 watts (Printing)
≥3m
7000-13000
115 x 230 mm
II
IPX0
1.98kg
machine
Lp = 86 dB(A) K= 3
A
dB(A)
Lw = 97 dB(A) K= 3
A
dB(A)
2
a = 5,8 m/s
h
2
m/s
The noise emitted by the device is described by: the emitted sound
pressure level Lp
measurement uncertainty). The vibrations emitted by the device are
described by the value of the vibration accelerations a
the measurement uncertainty).
The emitted sound pressure level Lp
and the acceleration value a
with EN 62841-1:2015. The stated vibration level a
compare devices and to initially assess vibration exposure.
The stated vibration level is representative only for the basic
applications of the device. If the device is used for other applications
or with other working tools, the vibration level may change. A higher
level of vibration will be affected by insufficient or too rare
maintenance of the device. The reasons given above may increase
the exposure to vibrations during the entire period of operation.
In order to accurately estimate the exposure to vibrations, it is
necessary to take into account the periods when the device is
turned off or when it is turned on but is not used for operation.
After a thorough estimation of all factors, the total vibration
exposure may turn out to be much lower.
In order to protect the user from the effects of vibrations, additional
safety measures should be introduced, such as: cyclical
maintenance of the device and working tools, protection of the
appropriate hand temperature and proper organization of work.
Electrically powered products should not be disposed of with household
waste, but should be disposed of in appropriate facilities. Information on
disposal is provided by the dealer of the product or local
authorities. Waste
substances that are not neutral for the natural environment. Non-recycled
equipment is a potential threat to the environment and human health..
"Grupa Topex Spółka z ograniczoną odpowiedzialnością" Spółka komandytowa with
its registered office in Warsaw, ul. Pograniczna 2/4 (hereinafter: "Grupa Topex")
informs that all copyrights to the content of this manual (hereinafter: the "Manual"),
including its text, photos, diagrams, drawings, and its compositions belong
exclusively to the Topex Group and are subject to legal protection in accordance with
the Act of February 4, 1994, on copyright and related rights (i.e. Journal of Laws of
2006 No. 90 Item 631, as amended). Copying, processing, publishing, modifying for
commercial purposes the entire Manual and its individual elements, without the
consent of Grupa Topex expressed in writing, is strictly prohibited and may result in
civil and criminal liability.
РУКОВОДСТВО ПО ПЕРЕВОДУ (ПОЛЬЗОВАТЕЛЯ)
ОРБИТАЛЬНАЯ ШЛИФОВАЛЬНАЯ МАШИНА
ВНИМАНИЕ:
ЭЛЕКТРОИНСТРУМЕНТА
ДАННОЕ
ДАЛЬНЕЙШЕГО ИСПОЛЬЗОВАНИЯ.
min-1
ПРЕДУПРЕЖДЕНИЯ ПО ТЕХНИКЕ БЕЗОПАСНОСТИ ПРИ
РАБОТЕ С ОРБИТАЛЬНОЙ ШЛИФОВАЛЬНОЙ МАШИНОЙ
Держите
поверхности,
соприкоснуться с его собственным проводом.
При повреждении провода, находящегося под напряжением,
открытые металлические части электроинструмента могут
оказаться под напряжением и привести к поражению оператора
электрическим током.
При шлифовании деревянных и металлических поверхностей,
например, окрашенных красками, содержащими свинец,
может образоваться вредная/токсичная пыль. Контакт или
вдыхание такой пыли может представлять опасность для
здоровья оператора или посторонних лиц. Следует
K = 1,5
пользоваться соответствующими средствами индивидуальной
защиты, такими как респираторы, защитные очки. Следует
подключить пылеудаляющую установку.
ПЕРЕД НАЧАЛОМ
МАШИНОЙ
7
and the sound power level Lw
A
, the sound power level Lw
A
have been measured in accordance
h
electrical and
RU
59G329
ПЕРЕД
ВНИМАТЕЛЬНО
РУКОВОДСТВО И СОХРАНИТЕ
электроинструмент
иначе шлифующая
РАБОТЫ СО
(where K is the
A
(where K is
h
A
can be used to
h
electronic equipment contains
ИСПОЛЬЗОВАНИЕМ
ПРОЧИТАЙТЕ
ЕГО ДЛЯ
за изолированные
поверхность может
ШЛИФОВАЛЬНОЙ
