Page EN-30 Set-up, connection and initial start-up
Having the outlet hose
connected
NOTICE
Malfunction!
Failing to connect the appliance cor-
rectly may cause malfunctions during
operation.
■ Make sure that the waste water can
drain freely at any time. To that end,
the outlet pipe must have a minimum
diameter of 40 mm.
■ Ensure that there are no kinks or dam-
age to the outlet hose.
■ Make sure that the end of the hose is
not submerged in the pumped water.
■ Do not extend the outlet hose or re-
place with another drainage pipe.
You can connect the end of the outlet hose in
two different ways:
– Connection to a floor drain.
– Direct connection to the odour seal (si-
phon) of your washing/dishwashing basin.
Technical measures are required for this.
For this reason, only plumbing experts or
members of our service department may
connect the outlet hose (see page EN-39).
The outlet hose must be a maximum of
1000 mm above the floor.
Ø ≥ 40 mm

Connecting the inlet hose

NOTICE
Risk of damage to property!
The dishwasher is set up for a water
pressure of 0.4 bar to 10 bar (0.04 MPa
to 1.0 MPa). Water must always be able
to run freely into the dishwasher, oth-
erwise this can damage the appliance.
■ If the water pressure is higher than
this, install a pressure reducer. If in
doubt, enquire about the water pres-
sure with the water supply company.
■ Never connect the appliance to the
water tap or the mixing arm of a wa-
ter heater (continuous fl ow heater,
pressure-free boiler etc.).
■ Ensure that the inlet hose is not
kinked and is carefully connected.
■ Do not cut through the inlet hose.
It contains electrical components. If
the inlet hose is damaged, have it re-
paired by a specialist (see "Service"
on page EN-39).
■ Do not use old or previously installed
inlet hoses.
3
¾ inch
Inlet hose
You will require a valve with a ¾-inch screw
connector for the water supply.
1. Screw the safety valve's lock nut to the
tap hand-tight.
2. Check that the connection to the water
tap is sealed. Turn on the water tap slow-
ly and ensure that no water is escaping.
Then close the tap again.
