ROUTER FOR FITTING HINGES FR1129T
(ILUSTRATIONS IN PAGE 30)
Important
Read these OPERATING INSTRUCTIONS and the
attached GENERAL SAFETY INSTRUCTIONS LEAFLET
carefully before using the machine. Make sure you
have understood them before operating the machine
for the first time.
Keep both sets of instructions for any future queries.
Important note
Carefully read the GENERAL SAFETY INSTRUCTION
LEAFLET enclosed with the machine documents.
2. Before plugging in the machine, make sure that the power supply
voltage is the same as that shown on the specifications plate.
3. Always keep hands clear of the cutting area. Always hold the ma-
chine safely.
4. Always use original VIRUTEX tools. Never use defective or damaged
tools.
5. Always use cutter bits with the appropriate stem diameter for the
chuck collet and tool speed to be used.
Unplug the machine from the mains before carrying
out any maintenance operations.
1. CHARACTERISTICS
Power............................................................................750 W
No load speed.....................................................30,000/min
Chuck diameter.............................................................8 mm
Weight..........................................................................4.3 kg
Weighted equivalent continuous acoustic pressure level A.......86 dBA
Acoustic power level A............................................................................97 dBA
Uncertainty................................................................................................K = 3 dBA
Wear ear protection!
Vibration total values.....................................................................a
Uncertainty...........................................................................................K: 1.5 m/s
2. DIMENSIONS
Lengthways displacement of cutter shaft.............145mm
Sideways displacement of cutter shaft................54 mm
Lengthways milling with cutter bit Ø: 16mm...........161 mm
Sideways milling with cutter bit Ø: 16mm................70 mm
6
E N G L I S H
Minimum opening between clamp vises...................33 mm
Maximum opening between clamp vises................200 mm
Cutter bit maximum diameter...............................32 mm
Maximum milling depth...............................................11 mm
The following concepts are dealt with in the different sections of this
manual. Please see (Fig. 1).
A = Width of rebate
B = Width of hinge wing
R = Depth of rebate (Interior side of rebate)
Door entry side
Door exit side
Right opening door
Left opening door
Minimum rebate required A (Fig. 1), for fitting a certain hinge with
the FR1129T and with template, should be at least the same width as
hinge wing B (Fig. 1) + 6 mm.
Templates for special hinges are manufactured in accordance with the
width of the rebate and not the thickness of the door, although both
measurements are normally the same, unless otherwise requested in
the order form. If the thickness of the door is less than the width of
the rebate, the hinge will fit correctly into the frame. However, in the
door the hinge cylinder will project from the door face by the difference
in the two thicknesses.

3. UNPACKING

Inside the transporting case the following items will be found (Fig.
2):
1. Router model FR1129T with cutter bit Ø: 7.6 mm (H.M.)
2. Base with template for 9.5 mm long hinges for doors with 35 mm
of rebate and template guide of 12 mm external diameter
3. Hinge distributor tube for three-hinge door
4. Hinge distributor tube for four-hinge door
5. Hinge distributor connector
6. Phillips screwd river
7. 11 mm wrench to block motor axle and secure pointers
8. 19 mm wrench for chuck securing nut
9. 4 mm allen wrench for adjusting frame/door gap
10. Centering attachment for reinforcing hinge.
4. ASSEMBLING THE ROUTER
Remove bolt C (Fig. 2).
Fit motor body 1 (Fig. 2) to the column on machine base 2 (Fig. 3).
Check the vertical movement of the motor body in the column.
Secure bolt C (Fig. 3).
Check that the template guide moves freely lengthways and sideways
in the template shape.
5. GENERAL DESCRIPTION OF THE ROUTER FOR FITTING
HINGUES
The machine is made up of the following components and performs
the following tasks:
5.1 Motor body 1 (Fig. 3), which, via the motor axis, supplies the necessary
power and revolutions to the miller to perform recessing.
5.2 Base 2 (Fig. 3), made up of template D (Fig. 3) and the components
for securing and regulating the frame and door, and which enables
motor body 1 (Fig. 3) to move sideways, lengthways and inwardly to
perform the routing of the recess. Base 2 (Fig. 3) allows the recesses
for the hinges to be placed on the frame, by placing it on the width
: < 2.5 m/s
2
h
of the rebate (Fig. 1 and 4), and stopping it on inner frame face R (Fig.
2
1 and 4) or on the thickness of the door (Fig. 13).
It is also possible to fit hinges to doors without rebates, taking the
reference from the outer frame face with screws C1 (Fig. 17), as ex-
plained in section 10.
Base 2 (Fig. 4) is secured to the frame or door by tightening clamp
vises E (Fig. 4), by turning crank handles F (Fig. 4).
