Motor Tag Information

The carrying handle on your RD Series pump contains important technical,
performance, and certification information. For your specific model
certification, reference the regulatory marks on your pumps handle. Be
certain this handle remains affixed to the pump at all times.

Technical Information

Motor
Power - DC 12, 24, 12/24
HP (horsepower) rating
Power cable length
Power cable gauge
Power cable DC battery connectors
Amps (FLA)
RPM
Duty cycle
Thermal Protection
Circuit protection fuse
Certification
Pump
Type - rotary, diaphragm, gear, vane
Flow Rate (with supplied hose / nozzle)
Flow Rate (open flow – no hose or nozzle)
Max discharge pressure
Dry vac (in Hg)
Head- Max (ft)
Anti-siphon valve
Inlet – Size / Thread
Outlet – Size / Thread
Mount
Materials of construction – pump housing
Materials of construction – wetted material
Rotor materials of construction
Rotor vane material of construction
Compatible fluids
Strainer Mesh Size
Warranty (year)
Maximum Sound Level
fillrite.com
RD SERIES FUEL TRANSFER PUMPS
30 min. ON / 30 min. OFF
Yes (30 Amp Fuse)
UL/cUL Motor/CE/ATEX/IECEx Pump
Rotary Hinged Vane
Up to 8 GPM / 30 LPM
Up to 10 GPM / 38 LPM
3/4" NPT / BSPP
3/4" NPT / BSPP
2" Bung (NPT) / BSPT
BUNA-N + HNBR
Diesel, Gasoline, BioDiesel up to B20, E15,
Kerosene, Mineral Spirits, Methanol (up to 15%)
RD8
12 VDC
1/6 HP
10'
14 AWG
Yes
14 A
3600
Yes
RD8
16 PSI
5 in vacuum
37'
None
Aluminum
Nylon
Acetal
20 x 20
2 Year
65 dB (A)
INSTALLATION AND OPERATION MANUAL
RD12
12 VDC
1/6 HP
10'
14 AWG
Yes
14 A
3600
30 min. ON / 30 min. OFF
Yes
Yes (30 Amp Fuse)
UL/cUL Motor/CE/ATEX/IECEx Pump
RD12
Rotary Hinged Vane
Up to 12 GPM / 45 LPM
Up to 13 GPM / 50 LPM
16 PSI
5 in vacuum
37'
None
3/4" NPT / BSPP
3/4" NPT / BSPP
2" Bung (NPT) / BSPT
Aluminum
BUNA-N + HNBR
Nylon
Acetal
Diesel, Gasoline, BioDiesel up to B20, E15,
Kerosene, Mineral Spirits, Methanol (up to 15%)
20 x 20
2 Year
65 dB (A)
