5 PROGRAMMING
5.10

Authorized values for the programmable parameters

Calibration menu
Measured pressure:
Displayed current:
OLO1 and 2 (*):
OHI1 and 2 (*):
DEL1 and 2 (*):
Filtre:
4 mA:
20 mA:
BGLO:
BGHI:
CODE:
Outside these ranges the transmitter does not validate the value but displays the nearest limit.
−999...9999
0.000...9999
−999...9999
−999...9999
0 s...999 s
0...9
−999...9999
−999...9999
−999...9999
−999...9999
0000...9999
Test menu
Simulated pressure:
Displayed Zero/K factor:
Adjusted Zero/K factor:
Reference pressure:
Adjusted 4 mA:
Adjusted 20 mA:
(*) Only versions with transistor outputs
Pressure transmitter 8311
−999...9999
−999...9999 %
−999...9999
−999...9999
3.5...4.5 mA
19...21 mA
