Components
62
26 Speed wheel
27 Camera angle wheel
28 Video shutter release
29 Photo shutter release
30 Front position LEDs (white)
31 Front rotors
32 Camera
33 33 Rotor arms
26
29
30
31
36
37
33
40
39
35
38
33
ENGLISH
34 Memory card compartment
35 Battery lock
36 Rear rotors
37 Rear position LEDs (blue)
38 USB connector Battery
39 Charge indicator LEDs
40 Power button
Quadrocopter
