TWINCUTTER
THE NUMBERS IN THE FOLLOWING TEXT
CORRESPOND WITH THE PICTURES AT PAGE 2
Cautions! Before using these products read this
manual and all instructions and follow all its safety
rules and operating Instructions.
THE SAW OF THE FUTURE IS HERE!
Congratulations for buying Twincutter. Twincutter is a
unique twin blade cutting system! Two specially
designed blades* spin in opposite directions, providing
smoother finished cuts with less vibration and kickback
than any single blade saw! Twincutter can do your work
faster and with negligible sparks. This feature makes it
suitable for jobs nearly inflammable materials without
fire hazard!
Because of the open carbon brushes, however,
Twincutter must not be used in areas with risk of
explosion.
Twincutter is providing effortless cutting with its
portability!
* World Patent Pending
CONTENTS:
1. Data Sheet
2. General safety rules for power tool & symbols
3. Specific safety rules for Twincutter
4. Know your Twincutter Saw
5. Operating Instruction
6. Instructions for Cutting Various Cross Sectional
Material
7. Removal of Used Twincutter Saw Blades
8. Mounting of Replacement Twincutter Saw Blade
9. Twincutter Saw Blades
10. Accessories
11. Maintenance

1. DATA SHEET

Model
Volts
Power
Frequency
Ø Blade
No load speed
Max. cutting depth
Lpa (Sound pressure level)
Lwa (Sound power level)
Vibration level
Ferm Ferm
Model
Volts
Power
Frequency
Ø Blade
No load speed
Max. cutting depth
Lpa (Sound pressure level)
Lwa (Sound power level)
Vibration level
STANDARD ACCESSORIES SUPPLIED WITH
THE MACHINE:
1 Blade guard (mounted)
1 Assist handle
1 Lubrication unit (mounted)
1 Box wax tube (containing six tubes)
1 Set (2 nos.) "universal" carbide blades (mounted,
refer to section TWINCUTTER BLADES)
2. GENERAL SAFETY RULES FOR
TWINCUTTER
SYMBOLS
Important! Some of the following symbols may
be used on your tool. Please study them and learn
their meaning. Proper interpretation of these symbols will
allow you to operate the tool better and safer.
V Volts
A Amperes
Hz Hertz
W Watt
Kg Kilograms
Min Minutes
s Seconds
Ø Diameter
n0 No load speed
.../min Revolutions or reciprocation per minute
Revolutions, strokes, surface speed, orbits
etc. per minute
Arrow
| FT-720
Action in the direction of arrow
| 230 V
| 720 W
Class II Construction
| 50 Hz
Designates Double Insulated Construction
| 125 mm
tools
| 5500/min
| 30 mm
Earthing terminal
| 73.1 dB
Grounding terminal
| 84.1 dB
| 10.2 m/s 2
Warning symbol
Alerts user to warning messages
Read the instructions
| FT-950
| 230 V
| 950 W
| 50 Hz
| 155 mm
| 4900/min
| 46 mm
| 76.4
| 87.4 dB
| 10.8 m/s 2
Voltage (potential)
Current
Frequency (cycles per
second)
Power
Weight
Time
Time
Size of drill bits, grinding
wheels, Saw blades etc.
Rotational speed, at
no load
