EXPLODED VIEW
SPARE PARTS LIST FT-720
REF NR DESCRIPTION
405600 GEAR BOX SUB ASSEMBLY
405601 SIDE HANDLE
405602 GEAR
405603 ROTOR
405604 SWITCH
405605 STATOR
405606 CARBON BRUSH (SET)
405607 FLANGE
405608 NUT
405609 SPANNER
405610 GUARD (SET)
74
Fig.8
Fig.9
Fig.10
FERM NR
11
12
14
16
38
41
50
52
53
54
Fig.11
58, 60 TILL 64
