5

Start-up

5.1

Teaching-in

Please read this entire section before starting the teach-in
procedure.
You can either pair the radiator thermostat directly with one or more
Homematic IP devices or teach-in the device to the Homematic IP
Access Point (HmIP-HAP). After direct pairing, configuration has to
be done directly on the device. After teaching-in to the Access Point,
configuration is done via the Homematic IP app.
5.1.1

Direct pairing with a Homematic IP device

You can directly pair the Homematic IP Radiator Thermostat – basic
to the Homematic IP Window/Door Contact with magnet (HmIP-
SWDM/HmIP-SWDM-2) and/or the Homematic IP Wall Thermostat
(HmIP-WTH-B/HmIP-WTH-B-2).
Please make sure you maintain a distance of at least 50 cm between
the devices.
You can cancel the pairing procedure by briefly pressing the system
button (D) again. This will be indicated by the device LED (D) lighting
up red.
To connect the device with another Homematic IP device, the pairing
mode of both devices has to be activated. To do this, please proceed as
follows:
Open the battery compartment (B) by pulling the battery
•
compartment down (see figure 3).
• Remove the insulation strip from the battery compartment.
Press and hold down the system button (D) for at least 4 seconds
•
to activate the teach-in mode (see figure 4). The device LED
(D) starts to flash orange. Pairing mode remains activated for 3
minutes.
• Press and hold down the system button of the device you want
Start-up
37
