OPERATING AND MAINTENANCE MANUAL PART 2
THE USER SHOULD KEEP THIS DOCUMENT
1. INTRODUCTION
This instruction manual is split into two booklets: PART 1, con-
taining general information regarding our whole product range;
and PART 2, containing information specific to the motor-driven
EN
pump you have purchased. The two publications are comple-
mentary to each other, so make sure you have both.
Comply with the instructions contained in them to get the most
out of your motor-driven pump and assure its proper operation.
If you need further information, get in touch with your nearest
authorized dealer.
If information in the two parts contradict each other, take PART
2 containing the product's specific information as valid.
NO PART OF THESE ILLUSTRATIONS AND/OR TEXT MAY BE
REPRODUCED FOR ANY REASON.
The following symbols have been used in the compilation of this
instruction booklet.
WARNING!
Risk of damaging the pump or system
Risk of causing injury or damaging property
Electrical hazard
2. CONTENTS
1. INTRODUCTION
2. CONTENTS
3. DESCRIPTION AND USE OF MOTOR-DRIVEN PUMP
4. SPECIFICATIONS
5. PREPARING FOR USE
6. STARTING
7. MAINTENANCE
8. INSTALLATION AND DISASSEMBLY DIAGRAMS
3. DESCRIPTION AND USE OF MOTOR-DRIVEN PUMP
3.1. DESCRIPTION
Description: SUBMERSIBLE MOTOR-DRIVEN PUMPS
Model: OPTIMA/BEST
RIGHT
DW - DW VOX
3.2. USE FOR WHICH PUMPS ARE DESIGNED
The motor-driven pumps can be used for:
− handling clear water (OPTIMA/BEST) as well as dirty or sew-
age water (RIGHT-DW) with solids in suspension up to the
diameter indicated in chap. 4;
− pumping water out of garages, cellars, basements, tanks,
reservoirs, fountains, rainwater drains;
− flood irrigation of vegetable patches and gardens and oxygen-
ating water. The DW series can also be used to drain rainwa-
ter drains, cesspits and septic tanks, and trenches etc..
WARNING!
ONLY USE RIGHT- AND DW-SERIES MOTOR-DRIVEN
PUMPS FOR CONTINUOUS DUTY IF THEY ARE FULLY
SUBMERSED.
DO NOT USE RIGHT – DW MOTOR-DRIVEN PUMPS
WITH THE MOTOR OUT OF WATER FOR MORE THAN 15
MINUTES.
6
Use the motor-driven pumps based on their technical speci-
fications.
3.3. USE FOR WHICH PUMPS ARE NOT DESIGNED
The pumps cannot be used to handle:
− water containing acids or bases, and corrosive liquids in gen-
eral;
− water with a temperature over the temperature limit given in
chap. 4.
− seawater;
− flammable liquids and hazardous liquids in general;
− cannot be used in swimming pools (according to EN 60335-2-41);
− pumps with a cable less than 10m long cannot be used out-
doors. (OPTIMA MS with 5 m cable is excluded from outdoor
usage)
The motor-driven pumps must never be made to work without
liquid.
4. SPECIFICATIONS
4.1. OPTIMA/BEST PUMP SPECIFICATIONS
Max. temperature
of liquid pumped
Max. size
of solids in
suspension
Max. immersion
depth
Delivery diameter
* = threading according to ISO 228
4.2. RIGHT – DW PUMP SPECIFICATIONS
page 6
page 6 Max. temperature
of liquid pumped
page 6
page 6
Max. size
page 6 of solids in
suspension
page 7
page 7
Max. immersion
page 60 depth
Delivery diameter
* = threading according to ISO 228
4.3. OPTIMA/BEST - RIGHT - DW MOTOR SPECIFICATIONS
TYPE
MAX. STARTS PER
HOUR
RATINGS
OVERLOAD
PROTECTION
4.4. RATING PLATES
The manufacturer reserves the right to make changes.
4.5. INFORMATION ON AIRBORNE NOISE
Given the type of use, the motor-driven pumps do not exceed an
A-weighted sound pressure emission level of 70 dB (A).
5. PREPARING FOR USE
WARNING!
USE A ROPE FASTENED AROUND THE HANDLE TO LIFT
OR LOWER THE MOTOR-DRIVEN PUMP: NEVER PULL THE
POWER CABLE AND/OR FLOAT CABLE AND SWITCH (FIG. 12).
U.M. OPTIMA BEST ONE BEST ONE VOX BEST 2-5
°C 50
mm 10 20
m See motor-driven pump rating plate
* G 1" ⁄
1
4
U.M. RIGHT DW
°C 50
mm 35
m See motor-driven pump rating plate
* G 1" ⁄ G 2" or DN 50 flange
1
2
OPTIMA
BEST 2-5 RIGHT
BEST ONE
Submersible
30 20
See motor-driven pump rating plate
SINGLE PHASE: thermal cutout w/automatic reset
THREE PHASE: by installer
35
10
G 1" ⁄
1
2
DW VOX
40
50
DW
