2. Press the enter button 1.
3. Move through the programming menu by
using the arrow buttons (LEFT and RIGHT),
to a new program no. (with "P?") or select an
existing program number.
4. Choose the program no. with "enter" button 1.
INFORMATION
+
If the control system does not accept any further entry, press the release button for a reset.
Start again from the beginning with the choice of a program no.
BDA AT-65 – 01/16
Seite/Page/Página 88 / 115
412-94313 Rev. A
#001
<
1
#020 P?
<
#010 P1
<
1
ECOC: EGC0 ; LOC: AI
>
Fig. 8.6
>
Fig. 8.7
>
Fig. 8.8
