TE Connectivity AT-65 Betriebsanleitung Seite 84

1-528050-1
After having started the hydraulic Crimp Machine AT-65 with the main switch and after having
turned the key switch (chapter 4.3.4/Abb. 4.6) to the left, you enter the
The standard display is shown.
The program menu uses simple graphic symbols to lead the operator through the
programming sequence. Moving through the menu is achieved by using arrow buttons. If you
want to select a menu item to edit, press the "Enter" button.
INFORMATION
+
To enter the
switch to the left
key can be withdrawn and thus prevent an unintentional change of the programs.
Symbols:
#
"P1", "P2", "P3", "P?" = Crimp cycle programs, "P?" = Program-type not yet chosen
Standard Display ("Production Mode"):
Program No.:
Program-Type.:
Completed Machine Cycles: "000000003"
Programming Display ("Program Mode")
Program No.
Program-Type.
Status of the program chosen
BDA AT-65 – 01/16
"Program Mode"
turn the key switch to the right. After having turned the key
("Production Mode"),
= Program memory position (e.g. #10 = program no. 10)
"#010"
"P1"
"#010"
"P1"
"OK"
Seite/Page/Página 84 / 115
"Program Mode"
the is locked. In this position the
412-94313 Rev. A
"Production
Mode".
#010 P1
000000003
Fig. 8.1
#010 P1
OK
Fig. 8.2
ECOC: EGC0 ; LOC: AI
