PART LIST

No. Description
1 Main frame
2 L/R Treadmill columns, left/right
3 Computer frame
4 Support
5 Front roller
6 Rear roller
7 Spring
8 Sleeve Φ18*8
9 Running board t15*530*1155
10 Running belt t1.4*450*2570
11 IGBT 130-J5
12 Upper computer cover
13 Lower computer cover
14 Rail foam cover left
15 Rail foam cover right
16 Upper motor cover
17 Lower motor cover
18 Internal cover of left treadmill
column
19 External cover of left treadmill
column
20 Internal cover of right treadmill
column
21 External cover of right treadmill
column
22 Treadmill column knob
23 Side rail
24 End cover
25 Handling wheel
26 Foot washer
27 Damper 1
28 Damper 2
29 "C" cap
30 Computer cover knob
25
Quantity No. Description
1 31 Rubber damping washers
1/1 32 Pulse sensor / Fast start-up
button Start/Stop
1 33 Pulse sensor / Fast speed change
buttons + / -
1 34 Controller
1 35 Safety wrench 950 mm
1 36 Motor
2 37 Power switch
2 38 AC adapter 1.8 m
1 39 250 V socket
1 40 Overload protection
1 41 Single cable 250 V 270 mm
1 42 Earthing 250 V 300 mm
1 43 Bolt M8*50
1 44 Screw 4.2*16
1 45 Screw 4.0*30
1 46 Screw 4.2*16
1 47 Screw M8*25
1 48 Screw 4.2*16
1 49 Screw 4.2*25
1 50 Screw M6*35
1 51 Screw M6*25
2 52 Screw M8*40
2 53 Screw M6*35
1 54 Bolt M8*12
4 55 Washer Φ9* Φ16*t1.5
2 56 Washer D8
4 57 Washer Φ5.2* Φ10*t1
2 58 Screw 3.5*10
2 59 Nut M6 S10
2 60 Washer Φ10.5* Φ20*t2.00
Quantity
2
1
1
1
1
1
1
1
1
1
2
1
3
28
4
17
2
12
7
4
4
4
2
2
4
4
1
1
2
2
