MA lighting 2Port Node Bedienungsanleitung Seite 38

Example of use 4
Example of use 5
Technischer Service: tech.support@malighting.com; +49.5251.688865-30 Emergency Line: +49.5251.688865-99
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn
DMX-out (max. 512 parameter)
Switch / hub
100 Mbit
DMX A -OUT / IN (512 parameter)
DMX B -OUT / IN (512 parameter)
Examples of use
The flush-mount version has a special feature:
Although in the flush-version, the 2Port can only
cooperate with a grandMA console, the laptop running
the onPC software would bridge a console breakdown
(see example on the left), carry on as Session Master
and produce DMX outputs. Using an onPC as backup,
however, is not a good solution.
