The following design models are available:
- Flush-mount version (Power over Ethernet) with 1,204 parameters, to be sunk-mounted in flush box according to EU standards
Cannot exclusively be operated with the „onPC" software.
MA2Port Node, flush-mounted box „EU version", 2x DMX in
MA2Port Node, flush-mounted box „EU version", 2x DMX out
MA2Port Node, flush-mounted box „EU version", 1x DMX in, 1x DMX out
- Flush-mount version (Power over Ethernet) with 1,204 parameters, to be sunk-mounted in flush box according to US standards
Cannot exclusively be operated with the „onPC" software.
MA2Port Node, flush-mounted box „US version", 2x DMX in
MA2Port Node, flush-mounted box „US version", 2x DMX out
MA2Port Node, flush-mounted box „US version", 1x DMX in, 1x DMX out
- Rigging box version ( incl. power supply) with 512 parameters and onPC / 1,024 parameters with console; using metric M12 threads
MA2Port Node rigg-mounted touring version incl. power supply, „EU version", 2x DMX in
MA2Port Node rigg-mounted touring version incl. power supply, „EU version", 2x DMX out
MA2Port Node rigg-mounted touring version incl. power supply, „EU version", 1x DMX in, 1x DMX out
- Rigging box version ( incl. power supply) with 512 parameters and onPC / 1,024 parameters with console; using ½" 13-UNC screw
threads basing on inch system
MA2Port Node rigg-mounted touring version incl. power supply, „US version", 2x DMX in
MA2Port Node rigg-mounted touring version incl. power supply, „US version", 2x DMX out
MA2Port Node rigg-mounted touring version incl. power supply, „US version", 1x DMX in, 1x DMX out
- Rigging box version (incl. power supply) with 1,024 parameters, using metric M12 threads
MA2Port Node PRO rigg-mounted touring version incl. power supply, „EU version", 2x DMX in
MA2Port Node PRO rigg-mounted touring version incl. power supply, „EU version", 2x DMX out
MA2Port Node PRO rigg-mounted touring version incl. power supply, „EU version", 1x DMX in, 1x DMX out
- Rigging box version (incl. power supply) with 1,024 parameters; using ½" 13-UNC screw threads basing on inch system
MA2Port Node PRO rigg-mounted touring version incl. power supply, „US version", 2x DMX in
MA2Port Node PRO rigg-mounted touring version incl. power supply, „US version", 2x DMX out
MA2Port Node PRO rigg-mounted touring version incl. power supply, „US version", 1x DMX in, 1x DMX out
If you want to be flexible in using the different variants, we offer DMX cables having distinct plug combinations and appropriate connectors.
