Examples Of Use - MA lighting 2Port Node Bedienungsanleitung

Switch / hub
100 Mbit
Example of use 1
DMX B -IN (512 parameter)
Technischer Service: tech.support@malighting.com; +49.5251.688865-30 Emergency Line: +49.5251.688865-99
MA Lighting Technology GmbH . Dachdeckerstr. 16 . D-97297 Waldbüttelbrunn
DMX A -out / in (512 parameter)
DMX B -out / in (512 parameter)
Switch / hub
100 Mbit
DMX A -OUT / IN (512 parameter)
Example of use 2

Examples of use

Installation:
The network must be of a 100Mbit type.
Options:
Output: 2x512 parameters / 2 Universes max. (i.e.
all channels output must be patched in the two
Universes.)
Example of use 3
37 37 37 37
37
