8.10. Field settings table

First Second
code code Setting name
0 User permission level
00 User permission level
1 Weather dependent set point
00 Low ambient temperature (Lo_A)
01 High ambient temperature (Hi_A)
02 Set point at low ambient temperature (Lo_Ti)
03 Set point at high ambient temperature (Hi_Ti)
05 Weather dependent for cooling function
enable/disable
06 Low ambient temperature (Lo2_A)
07 High ambient temperature (Hi2_A)
08 Set point at low ambient temperature (Lo2_Ti)
09 Set point at high ambient temperature (Hi2_Ti)
2 Disinfection function
00 Operation interval
01 Status
02 Start time
03 Set point (only in combination with domestic hot
water tank without electrical booster heater
(RKHTS), [4-03]=5)
03 Set point (only in combination with domestic hot
water tank with built-in electrical booster heater
(RKHW*), [4-03]≠5)
04 Interval (only in combination with domestic hot
water tank without electrical booster heater
(RKHTS), [4-03]=5)
04 Interval (only in combination with domestic hot
water tank with built-in electrical booster heater
(RKHW*), [4-03]≠5)
3 Auto restart
00 Status
4 Backup/booster heater operation and space heating off temperature
00 Backup heater operation (only in combination with
domestic hot water tank without electrical booster
heater (RKHTS))
00 Backup heater operation (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*))
01 Backup/booster heater priority
02 Space heating off temperature
03 Booster heater operation (only in combination with
domestic hot water tank without electrical booster
heater (RKHTS))
03 Booster heater operation (only in combination with
domestic hot water tank with built-in electrical
booster heater (RKHW*))
04 Not applicable.
05 Not applicable.
06 Backup heater emergency operation
07 Backup heater second step
