ECHNICAL SPECIFICATIONS

12.1. General

Nominal capacity
• cooling
• heating
Dimensions H x W x D
Weight
• machine weight
• operation weight
Connections
• water inlet/outlet
• water drain
• refrigerant liquid side
• refrigerant gas side
Expansion vessel
• volume
• maximum working pressure (MWP)
Pump
• type
• no. of speed
Sound pressure level
Internal water volume
Pressure relief valve water circuit
Operation range - water side
• heating
• cooling
Operation range - air side
• heating
• cooling
• domestic hot water by heat pump
(a) MBSP = Male British Standard Pipe
12.2. Electrical specifications
Standard unit (power supply via outdoor unit)
• power supply
Backup heater
• power supply
• maximum running current
Installation manual
50
All manuals and user guides at all-guides.com
Heating/cooling models (RKHBX)
922 x 502 x 361
48 kg
61 kg
(a)
1-1/4" MBSP
hose nipple
Ø9.5 mm (3/8 inch)
Ø15.9 mm (5/8 inch)
10 l
3 bar
water cooled
3
Refer to technical data
5.5 l
3 bar
+15~+55°C
+5~+22°C
–20~+35°C
+10~+46°C
–20~+35°C
Heating/cooling models (RKHBX)
See "Connection of the backup heater power supply" on page 20
See "Connection of the backup heater power supply" on page 20
Heating only models (RKHBH)
Refer to the Technical Data
Refer to the Technical Data
922 x 502 x 361
1-1/4" MBSP
hose nipple
Ø9.5 mm (3/8 inch)
Ø15.9 mm (5/8 inch)
water cooled
Refer to technical data
+15~+55°C
–20~+35°C
–20~+35°C
Heating only models (RKHBH)
230 V 50 Hz 1P
Indoor unit for air to water heat pump system
48 kg
61 kg
(a)
10 l
3 bar
3
5.5 l
3 bar
—
—
RKHBH/X016BB
