3 Device description
1
2
3
Figure 3.1 Front view
8
9
Figure 3.2 Rear view
32
1 Protective cover
2 Handle for opening the protective cover
3 Wire insertion funnel
4 Reel holder
5 Wire-end ferrule reel
10 6 Wire-end ferrule strip
7 Touch display
11
8 PC USB connection
9 Type plate
12
10 On/off switch
11 Fuse compartment
12 Mains connection socket
4
5
6
7
