1. Introduction

Manufacturer:
scheppach
Fabrikation von Holzbearbeitungsmaschinen GmbH
Günzburger Straße 69
D­89335 Ichenhausen
Dear customer,
We hope your new tool brings you much enjoyment
and success.
Note:
According to the applicable product liability laws, the
manufacturer of the device does not assume liability
for damages to the product or damages caused by
the product that occurs due to:
• Improper handling
• Non­compliance of the operating instructions
• Repairs by third parties, not by authorized service
technicians
• Installation and replacement of non­original spare
parts
• Application other than specified
We recommend:
Read through the complete text in the operating in­
structions before installing and commissioning the
device.
The operating instructions are intended to help the
user to become familiar with the machine and take
advantage of its application possibilities in accord­
ance with the recommendations.
The operating instructions contain important informa­
tion on how to operate the machine safely, profes­
sionally and economically, how to avoid danger, cost­
ly repairs, reduce downtimes and how to increase
reliability and service life of the machine.
In addition to the safety regulations in the operating
instructions, you have to meet the applicable regula­
tions that apply for the operation of the machine in
your country.
Keep the operating instructions package with the
machine at all times and store it in a plastic cover to
protect it from dirt and moisture. Read the instruction
manual each time before operating the machine and
carefully follow its information.
The machine can only be operated by persons who
were instructed concerning the operation of the ma­
chine and who are informed about the associated
dangers. The minimum age requirement must be
complied with.
In addition to the safety instructions contained in this
operating manual and the specific regulations of your
country, the technical rules generally accepted for the
operation of machines of the same type must be ob­
served.
 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
We accept no liability for damage or accidents which
arise due to non­observance of these instructions
and the safety information.

2. Layout

Paint spray gun with gravity-feed can
1a Nozzle
1b Paint Flow Regulator
1c Trigger
1d Paint Container
1e Flow Regulator
1f Quick Coupling Connector
Tire pressure gauge
2a Manometer
2b Deflation Button
2c Quick Coupling Connector
2d Trigger
2e Valve Connection
2f Universal adapter
2g Valve adapter, e.g. for cycle tyre valves
2h Ball needle
Compressed-air gun + suction-feed can
3a Nozzle
3b Container
3c Trigger
3d Quick Coupling Connector
Compressed-air gun
4a Nozzle
4b Trigger
4c Quick Coupling Connector
Compressed-air hose
5a Air Tool Connection
5b Quick Coupling Connector

3. Scope of delivery

• Open the packaging and remove the device care­
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available)
• Check that the delivery is complete.
• Check the device and its spare parts for possible
damage caused by transportation. In the event of
complaints, you must contact the distributor without
delay. Claims at a later stage will not be accepted.
• If possible, store the packaging until the warranty
period has expired
• Before handling the device, make yourself familiar
with it by reading the operating instructions.
• For accessories, consumables and spare parts,
only use original parts. Spare parts are available
from your stockist.
• Include our item number, the device model and
year of manufacture in your order.
