8.2 Körpermaße
8.2.1 Flansch Anschluss Code 8
FTF
DN
FTF
ø D
15
-
-
20
-
-
25
-
-
32
-
-
40
-
-
50
230,0
165,0
Maße in mm
n = Anzahl der Schrauben
1) Anschlussart
Code 8: Flansch EN 1092, PN 16, Form B, Baulänge FTF EN 558 Reihe 1, ISO 5752, basic series 1
2) Werkstoff Ventilkörper
Code 37: 1.4408, Feinguss
Code 90: EN-GJS-400-18-LT (GGG 40.3)
