Noise/Vibration Information; Declarations Of Conformity - Protool DRP 32-4 Handbuch

Noise/vibration information

Levels determined in accordance with EN 60 745
are typically:
DRP 32-4:
Sound pressure level
Noise level
Uncertainty
CAUTION
Operating noise
Damage to hearing
► Use ear protection!
Vibration emission value a
three directions) and uncertainty K measured in
accordance with EN 60 745: a
Uncertainty
The emission values specified (vibration, noise)
were measured in accordance with the test
conditions stipulated in EN 60 745 and are
intended for machine comparisons. They are
also used for making preliminary estimates
regarding vibration and noise loads during
operation.
The emission values specified refer to the
main applications for which the power tool is
used. If the electric power tool is used for other
applications, with other tools or is not maintained
sufficiently prior to operation, however, the
vibration and noise load may be higher when the
tool is used.
Take into account any machine idling times
and downtimes to estimate these values more
accurately for a specified time period. This may
significantly reduce the load during the machine
operating period.
L = 88 dB (A)
PA
L = 99 dB (A)
WA
K = 3 dB (A)
(vector sum for
h
= 2,5 m/s
2
h
K = 1 m/s
2

Declarations of Conformity

Hand Operated Drilling Machine
DRP 32-4
We declare under our sole responsibility that
this product is in conformity with the following
standards or standardization documents:
EN 55 014-1, EN 55 014-2, EN 50 366,
EN 60 745-1, EN 61 000-3-2, EN 61 000-3-3,
EN 60 745-2-1 according to the provisions of the
regulations 2004/108/EC and 2006/42/EC.
All the procedures were applied as validly
amended at the time of the issue of this
declaration, without quoting these.
Technical documentation is kept at the
manufacturer.
10
Stanislav Jakeš
Research and development
Protool GmbH
Wertstr. 20
D-73240 Wendlingen
30. 4. 2010
Serial no.
623313
11
