03.2004
200
380
485
380
Fig. 7-6
Siemens AG 6SE7087-6CX87-2DA0
SIMOVERT MASTERDRIVES
200
∅ 10,5
Brake resistor for
170 kW; 2.35 Ω
200 kW; 3.1 Ω
200 kW; 4.45 Ω
Mounting diagram, brake resistor for floor mounting
Bremseinheit / Braking Unit
710
740
755
Stud terminals, M12
Box dimensions: Folding box
760 x 500 x 1350
on Euro-pallet
Type
6SE7032-7ES87-2DC0
6SE7032-5FS87-2DC0
6SE7032-1HS87-2DC0
Technical Data
Pg11
Pg36
T1 / T2
Socket terminal
2
2.5 mm
M12
Weight, approx.
103 kg
95 kg
101 kg
7-7
