Technical Data
Floor mounting
100
380
485
380
Fig. 7-3
7-4
100
∅ 9
100
Brake resistor for
20 kW; 5 Ω
20 kW; 20 Ω
20 kW; 31 Ω
20 kW; 44.4 Ω
Mounting diagram, brake resistor for floor and wall mounting
Bremseinheit / Braking Unit
T1 / T2
Socket terminal, 2.5 mm
400
430
Stud terminals, M6
Wall mounting
Box dimensions: 450 x 500 x 320
Type
6SE7026-3CS87-2DC0
6SE7023-2ES87-2DC0
6SE7022-5FS87-2DC0
6SE7022-1HS87-2DC0
6SE7087-6CX87-2DA0
SIMOVERT MASTERDRIVES
03.2004
2
Pg11
Pg21
M6
400
Pg
Weight, approx.
15 kg
17 kg
17 kg
16 kg
