Start-up
Forming
A
C
R
Fig. 6-1
Fig. 6-2
6-4
-X38
1
208 V < Un < 415 V SKD 50 / 12
380 V < Un < 460 V SKD 62 / 16
500 V < Un < 690 V SKD 62 / 18
Circuit for forming
Forming
6
time in h
5
4
3
2
1
1 2 3
Forming time as a function of the time during which the converter was
non-operational
Bremseinheit / Braking Unit
C/L+ D/L-
O AMP
V
LOAD
E
TEMP
R
READY
RESET
PE
G H
Recommended components
A R
220 Ω / 100 W
470 Ω / 100 W
680 Ω / 100 W
4 5
Non-operational
time in years
6SE7087-6CX87-2DA0
SIMOVERT MASTERDRIVES
03.2004
PE1
PE2
C
22 nF / 1600 V
22 nF / 1600 V
22 nF / 1600 V
