Siemens simovert masterdrives Betriebsanleitung Seite 63

03.2004
Floor mounting
100
380
485
380
Fig. 7-4
Siemens AG 6SE7087-6CX87-2DA0
SIMOVERT MASTERDRIVES
100
∅ 9
100
Brake resistor for
50 kW; 8 Ω
50 kW; 12.4 Ω
50 kW; 17.8 Ω
Mounting diagram, brake resistor for floor and wall mounting
Bremseinheit / Braking Unit
T1 / T2
Socket terminal, 2.5 mm
710
740
Stud terminals, M6
Wall mounting
Box dimensions: 760 x 500 x 320
Type
6SE7028-0ES87-2DC0
6SE7026-4FS87-2DC0
6SE7025-3HS87-2DC0
Technical Data
2
Pg11
Pg21
M8
710
Pg
Weight, approx.
27 kg
27 kg
28 kg
7-5
