M-SO
PRCO PR1-8
SPCO SP01-15
ALL
RED
TEST
GREEN
BLUE
STND
DSPL
REV
REST REST/ON

DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features. The individual channels and their features are listed under DMX-protocol.

Addressing

The Control Board allows you to assign the DMX starting address, which is defined as the first channel from
which the LED PAR-64 Short 36x3Wwill respond to the controller.
If you set, for example, the address to channel 6, the LED PAR-64 Short 36x3W will use the channel 6 to 10
for control.
Please, be sure that you don't have any overlapping channels in order to control each LED PAR-64 Short
36x3W correctly and independently from any other fixture on the DMX-chain.
If several LED PAR-64 RGB 36 x 3W are addressed similarly, they will work synchronically.
Press the Menu-buttons and the Up/Down-buttons for setting the desired starting address. Now you can start
operating the LED PAR-64 Short 36x3W via your lighting controller.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last lighting in the link in order to
ensure proper transmission on the DMX data link.
Sound-controlled mode
With this function, you can adjust the sound-controlled mode.
Please note: On the rear panel of the device you can find an XLR-jack
(DMX Out) and an XLR-plug (DMX In), which can be used for connecting
several devices.
Choose the device which is to control the effects. This device then works as
master-device and controls all other slave-devices, which are to be
connected to the master-device via a balanced microphone lead. Connect
the DMX OUT-jack with the DMX IN-plug of the next device.
Set to DMX mode with DMX address 001 for all slave-devices.
Built-in program setting
With the function "PR. 1-8" you can run the internal programs.
Pr. 1 – 4 switching
Pr. 5 – 8 fading
Program speed setting
With this function you can set the program speed.
With this function you can test all LEDs for (correct) operation.
With this function you can test the red LEDs for (correct) operation.
With this function you can test the green LEDs for (correct) operation.
With this function you can test the blue LEDs for (correct) operation.
Display setting
With this function you can to turn the display upside down.
Reset
With this function you can restore the factory settings of the device.
