Aesculap Neurosurgery
MINOP optics and angled optics
To remove residues of cleaning/disinfecting agents,
always wipe distal window 1, illumination
surface 4 of the light cable connection, and
eyepiece window 6 with a swap moistened with
alcohol.
Mechanical alkaline cleaning and thermal disinfecting
Machine type: Single-chamber washer/disinfector without ultrasound
Stage Step
I Prerinse
II Cleaning
III Rinse I
IV Rinse II
V Thermal disinfecting
VI
Drying
D–W: Drinking water
FD–W: Fully desalinated water (demineralized, low microbiological contamination:
max. 10 microorganisms/ml, low endotoxin: max. 0.25 endotoxin units/ml)
10
T t Water
[°C/°F] [min] quality
<25/77 2 D–W
55/131 10 D–W
>10/50 1 D–W
>10/50 1 FD–W
90/194 5 FD–W
- -
Chemical/Note
-
neodischer MediClean forte 0.5 %
(5 ml/L) pH >10
-
-
-
- According to disinfector program
