CMi C-B-RM-40 Originalbetriebsanleitung Seite 44

GB
What?
Check and, if nec-
essary tighten, all
screw connec-
tions.
Check cable of the
pull-starter for
damage
Check motor oil
level
After each use
What?
Cleaning the prod-
uct
Every 25 hours of operation
What?
Cleaning the spark
plug
Replacing the air
filter
All 100 operating hours or once in year
What?
Replacing the
spark plug
Cleaning the product
Clean the product immediately after each
use. Dried-on grass is extremely hard and dif-
ficult to remove.
– Remove residual grass using a brush or
plastic scraper (do not use any sharp
implements).
– Remove deposits from the wheels.
– Wipe down the product with a slightly
damp cloth.
– Never clean the product with water or
high-pressure jet.
Changing the blades
DANGER! Risk of injury! Never
hold the blade by the cutting edge.
Wear protective gloves when working
with the blade.
► P. 5, item 7
– Lift the machine at the front and set it on
end.
44
How?
Hand-tighten the screw
connections using the
appropriate tool.
Visual inspection.
► Risks caused by vi-
brations – p. 39
How?
► Cleaning the pro-
duct – p. 44
How?
► Cleaning the spark
plug – p. 45
► Replacing the air fil-
ter – p. 44
How?
► Replacing the spark
plug – p. 45, Replace-
ment spark plugs:
► Risks caused by vi-
brations – p. 39.
Disassembly
– Loosen the blade screw (18) using a 14
mm hexagon spanner.
– Remove the washer (20).
– Carefully remove the blade (17).
Installation
NOTICE! Risk of product damage!
Ensure the correct installation posi-
tion: the journals (19) must line up
with the holes in the blade.
– Carefully put the blade (17) into place.
– Put the washer (20) into place.
– Tighten the blade screw (18) using a 14
mm hexagon spanner (35-40 Nm).
Replacing the air filter
NOTICE! Risk of product damage!
The product must never be operated
without the air filter, as this can cause
damage to the motor.
NOTICE! Risk of product damage!
Always use original air filters
approved by the manufacturer.
► P. 6, item 8
– Switch off the motor and remove the spark
plug connector.
– Open the air filter housing (12).
► P. 6, item 9
– Remove the air filter (21).
– Clean all parts of the air filter unit.
– Fit new air filter.
– Re-close the air filter housing (12).
Checking the motor oil level
► P. 6, item 10
– Unscrew and remove the motor oil filling
plug (8).
– Read-off the oil level on the dip stick on
the underside of the motor oil filling plug.
– The oil level must lie between [A] and [B].
Cleaning/replacing the spark plug
► P. 3, item 2
WARNING! Risk of injury due to
high-voltage! Do not touch the spark
plug connector and spark plug while
the motor is running.
► P. 6, item 11
– Disconnect the spark plug connector (13).
► P. 6, item 12
– Unscrew the spark plug (22) using a spark
plug spanner.
