1 Notes on the
operating manual
We are glad that you have chosen our
product and we would like to thank you
for your trust!
This operating manual contains informa-
tion and instructions for safe assembly,
activation, installation and maintenance,
as well as proper operation of the smoke
alarm device.
The operating manual is intended to in-
crease the reliability and life cycle, and
to help avoid hazards and downtime, or
a loss of warranty claims.
It is absolutely necessary that the oper-
ating manual is read and understood.
For a better readability, the XSD100
smoke alarm device is hereinafter re-
ferred to as "smoke alarm device" or
"device".
32 Operating Manual: XSD100 - Smoke Alarm Device
1.1 Scope of the operating
manual
The operating manual applies only to
smoke detectors of the XSD100 type with
or without "Q" label.
1.2 Name plate and
identification
The name plate of the smoke alarm de-
vice is located below the testing/stop
button (smoke alarm device cover).
Smoke detector with "Q" label Smoke detector with "Q" label
A smoke detector with "Q" label has a
on the name plate.
EN
1.3 Conformity
The XSD100 smoke alarm device with
"Q" label is certified according to:
vfdb guideline 14/01 (Q)
•
Regulation (EU) No 305/2011
•
according to EN 14604:2005/AC:2008
21
1772-CPR-210049
Variante: V3-Q
For more information about the "Q" label
and the vfdb guideline, please visit our
website at pyrexx.com.
EN
EN EN
Conformity in accordance with Conformity in accordance with
EN 14604:2005/AC:2008 (CE) EN 14604:2005/AC:2008 (CE)
The smoke alarm device is certified as a
construction product in accordance with
Directive (EU) No. 305/2011 according
to EN 14604:2005/AC:2008 (CE). The
production is monitored for unchanged
compliance with legal and normative re-
quirements by periodic and independent
checks.
The Declaration of Performance for
smoke detectors without "Q" label is
available at the following reference num-
ber at the manufacturer: k_89246
The Declaration of Performance for
smoke detectors with "Q" label is availa-
ble at the following reference number at
the manufacturer: k_503411
1.4 Safekeeping of the
operating manual
The operating manual is an important
component of the smoke alarm device,
and must always be kept at hand near the
installation location.

1.5 Symbols used
