• Remove the air filter cover (Fig.19/Pos.A) by loos-
ening the thumbscrew (Fig.19/Pos.B1)
• Loosen the thumb screw (Fig.20 / Pos.B2) and re-
move the air filter (Fig.20/Pos.14)
• Clean the air filter by tapping , replace if neces-
sary.
• Reassemble in reverse order.
m WARNING
NEVER use gasoline or cleaning solvents with a low
flash point to clean the air fi lter element. A fire or
explosion could result.
NOTE
Never run the engine without or with a damaged air
fi lter. Dirt gets so into the engine, causing serious
engine damage can occur. In this case, seller, and
manufacturer disassociate from any warranty.
Check, clean and replace spark plug (13)
(Fig.11/15)
Check the spark plug (13) after 10 hours on dirt and
grime. If necessary, clean it with a copper wire brush.
Maintenance the spark plug after 50 hours of opera-
tion.
• Remove the spark plug ignition cable (25).
• Remove any dirt from the base of the spark plug
(13).
• Use a wrench to remove the spark plug (13).
• Check the spark plug (13) visually. Remove any
debris with a wire brush.
• Look for discolouration on the top of the spark
plug. By default, the colour should be bright.
• Check the spark plug gap. An acceptable gap
width is 0.6 to 0.7 mm (see Fig.11).
• Remove the spark plug (13)carefully by hand.
• If the spark plug (13) has been inserted, tighten
them with a spark plug wrench.
• Attach the spark plug connector (25) at the spark
plug (13).
Note
Loosen spark plug can overheat and damage the en-
gine. And over tightening the spark plug can damage
the threads in the cylinder head.
Lubrication drive chain (Fig.9-10)
Remove cover (Fig.9 Pos.A) concerning the screws
(19). Regrease drive chain (24) every 500 operating
hours. Recap the opening with the lid (Fig.9 Pos.A)
and the screws (19) after servicing.
Disassembling wheels (Fig.6)
For maintenance disassemble the wheels as shown
in figure 6.
Cleaning
• Keep all safety devices, air vents and the motor
housing free of dirt and dust. Wipe the equipment
with a clean cloth or clean it with compressed air
at low pressure.
• We recommend that you clean your device after
each use.
• Clean the unit regularly with a damp cloth and
some soft soap. Do not use cleaning agents or
solvents; they may damage the plastic parts of the
appliance. Make sure that no water can get inside
the unit.
 www.scheppach.com  service@scheppach.com  +(49)-08223-4002-99  +(49)-08223-4002-58

10. Storage

1. Perform all general maintenance, which are in
the User's Guide in the Maintenance section.
2. Let the fuel out of the tank (Use a commercially
plastic fuel pump from the hardware store).
3. After the fuel is drained, start the machine.
4. Let the machine in idlespeed running until it
stops. That cleans the carburetor from the re-
maining fuel.
5. Let the machine cool down. (about 5 minutes)
6. Remove the spark plug.
7. Fill a small amount of 2-stroke engine oil into the
fi ring chamber. Pull out several times the starter
cord gently to wet the internal components with
the oil.
8. Replace the spark plug.
9. Clean the outer casing of the machine.
m Do not use strong detergents or petroleum
based cleaners when cleaning plastic parts.
Chemicals can damage plastics.
10. Store your machine on a straight bottom in a
clean, dry building with good ventilation.
m Do not store the machine with fuel in a non-
ventilated area where fuel fumes may reach
flame, sparks, pilot lights or any ignition sourc-
es.
Recommissioning
1. Remove the spark plug.
2. Pull the starter rope out several times. It cleans
the fi ring chamber of oil residues.
3. Clean the spark plug contacts or install a new
spark plug.
4. Fill the tank.

11. Transport

m WARNING
Let the engine cool down before transporting the ma-
chine or storing indoors to avoid burns or fi re haz-
ards. If you want to transport the unit empty the fuel
tank before. Clean the unit with a brush or a broom
of coarse dirt.

12. Disposal and recycling

The disposal instructions are based on icons placed
on the appliance or its package. A description of the
individual meanings, is shown in chapter "Explana-
tion of symbols on the device".
Transport package disposal
The package protects the appliance against damage
during transport. Packing materials are usually cho-
sen depending on their environmental friendliness
and disposal method and can therefore be recycled.
Returning the package to material circulation saves
raw materials and reduces waste disposal costs.
Parts of packages (e.g. foils, styropor®) can be dan-
gerous to children.Risk of suffocation! Keep parts of
packages away from children and dispose them as
soon as possible.
