5.2

Preparation and adjustment (RSE Multi)

The pipe end peeler RSE Multi must be adjusted to the pipe dimension prior to use.
Step
1 Checking the current setting
Check if the current setting is the correct one for the pipe respective fitting to be peeled.
If the current setting is not correct, it must be adjusted accordingly.
2 Changing the setting: loosening the locking nut
Install the handle on the bit and turn it counterclockwise to loosen the locking nut and to change the adjustment.
3 Changing the setting: Moving the spindle
Move the spindle to the correct dimensional setting.
Action
