Instruction manual
5

Operation

Due to the features of the tool, like the quick adjustment, the ovality compensation and the tiltable blade, an easy adjusting and ins-
tallation of the tool on various pipe dimensions as well as an even chip removal on pipes with ovalities or conical ends can be easily
performed.
The following description of the peeling process with the pipe end peeler RSE is exemplary for all variants of the
products. But in any use-case the correct insert must be used and the peeler must be adjusted to the correct pipe
dimension and SDR value.
Use cordless drill whenever possible. Recommended max. speed = 200rpm.
5.1

Preparation

Step
1 Cleaning the pipe
Clean pipe with Tangit PE cleaner and lint-free, colorless and clean cloth.
Remove mud, sand and dirt from the surface you want to peel.
This avoids damage of the peeling blade and extends its lifetime expectancy.
2 Mark required peeling length
Measure area which must be peeled on the still packed fitting with a yardstick and then mark on the pipe with an addition
of approx. 1 cm.
3 Bring the peeler arm to the upper position
Check if the peeling arm is in the upper position. If not, move it into this position by pushing down the short end of the
peeler arm and turning the locking wheel.
30
Action
