Construction

4.1

RSE (single dimension)

1
5
1 Peeling blade
2 Peeler arm
3 Locking wheel
4 Handle
4.2

Technical data RSE

Pipe dimension [mm]
Suitable for pipes made of
Max. Peeling length [mm]
Peeling depth [mm]
Product dimension [mm]
Packaging dimension [mm]
Packaging type
Transport weight [kg]
28
2
6
5 Insert
6 Spindle
7 Peeler body
8 Hexagon bit
Pipe end peeler RSE, d20 – 75mm SDR11
20 25
Dimension, weight and packaging
290x62x53 290x62x53
300x60x60 300x60x60
0.60 0.65
3
7
32 40
PE100RC, PE100, PE-Xa, PP
85
approx. 0.2 (according DVS 2207-1)
290x62x53 290x62x53
300x60x60 300x60x60
Plastic Box
0.65 0.70
4
8
50 63
290x62x53 290x75x35
300x70x70 300x90x90
0.80 1.00
75
290x87x35
300x95x95
1.15
