7. Specifications Notes
Antenna type ....................................................... Off-set dish
Users .......................................................................... 1
LNB type .................................................................. Universal LNB
Frequency band ................................................. Ku band
Frequency range ................................................ 10.7 GHz to 12.75 GHz
LNB gain .................................................................. 33 dBi
Receiving power ................................................ 49 dBW
Polarization ............................................................ V / H
Motor control ....................................................... 2-axis DC motor
Elevation.................................................................. 15° to 62°
Search angle ......................................................... 360°
Rotation speed .................................................... 50° per second
Search time ........................................................... 1 - 2 minutes
Temperature range ........................................... -25° C to + 70° C
Power supply ........................................................ 12 VDC @ 5 A
Weight ...................................................................... 9 kg (Shipman) / 12 kg (Shipman GPS/AS)
Dimensions dish ................................................. 460 x 320 mm (W / H)
Dimensions antenna ....................................... 670 x 400 mm (Ø / H)
Dimensions control unit ............................... 262 x 49 x 151 mm (W / H / D)
Note:
Weight and dimensions are not absolutely exact values.
Technical details are subject to change at any time without notice.

Declaration of Conformity

This complies with the following directives / standards is confirmed:
Electromagnetic Compatibility Directive 2004/108/EC
EN 55013: 2001 + A1: 2003 + A2: 2006
EN 55020: 2007
EN 61000-3-2:2006 + A1:2009 + A2:2009
EN 61000-3-3:2008
Low Voltage Directive 2006/95/EG
EN 60065: 2002 + A1: 2006 + A11: 2008
