Content
1. Introduction
1.1 General Information ....................................................................................................... 03
1.2 Unpacking............................................................................................................................. 03
1.3 Delivery ................................................................................................................................... 03
1.4 System Components...................................................................................................... 04
2. Installation
2.1 Installation ............................................................................................................................ 05
2.2 Gluing instructions .......................................................................................................... 06
2.3 Connecting the components ................................................................................... 07
2.4 The Control unit................................................................................................................. 08
2.5 Selecting the location ................................................................................................... 09
2.6 Startup and operation ................................................................................................... 10
2.7 Skew setting values for European capitals ....................................................... 11
3. Troubleshooting ...................................................................................................................... 12
4. Footprint ........................................................................................................................................ 13
5. Firmware Update ..................................................................................................................... 14
6. Specifications ............................................................................................................................. 16
02
ENGLISH
1. Introduction
1.1 General Information
Please read the manual thoroughly before operating the equipment. In case of incorrect
or improper handling of the warranty becomes void.
Note: If you have already installed similar products, the procedure does not
necessarily coincide with this product.
Warning: The antenna is not suitable for use in salt water, as it may cause cor-
rosion on the components of the antenna. The use in the immediate vicinity
of salt water will void the warranty.
1.2 Unpacking
1.3 Delivery
• Control unit (IDU) incl. powercable
• 1x antenna cable (10 m)
• 1x antenna cable (1 m)
• Installation glue (optional)
• Power supply 230 V (12 V, 5 A) (optional)
• User manual
Warning: transport lock
Then remove with the „LOCK"
marked screw on the bottom
of the antenna.
ENGLISH
03
